Timescale

We do not intend to discuss the features of PostgreSQL (storage mechanisms, high availability, security, ACID compliance and so forth), since these are well-known. What Timescale has done is to implement what the company calls a “hypertable” as an abstraction layer on top of the relational underpinnings of PostgreSQL. This abstraction provides a single continuous table across all space and time intervals, which is sharded into what are known as “chunks”, with the size of each chunk either set by the database or you can manually tune this to improve performance based on specific use cases. Indexes for chunks are stored in memory and there are also various query optimisation functions built into the product. All of this is designed to minimise the time required to run queries, which are typically based on a combination of the required time intervals and the type of data within the chunk (tick data, sensor data, location data and so on). Note that both the database optimiser, and the product’s ingestion capabilities, understand chunks.

One notable limitation is that, currently, TimescaleDB is limited to running on a single node. However, the company has announced (August 2019) a distributed version of TimescaleDB, which is currently in private beta and is scheduled for availability in 2020. While it is too early to comment on this in detail, initial testing by the company suggests that a nine-node cluster will support an ingestion rate in excess of twelve million metrics per second. Another significant capability that is in development is an improved compression capability compared to the native PostgreSQL ZFS protocol. This is important because of the volume of data that often has to be ingested and stored in time-series environments.

Some notable features provided by Timescale include built-in support for various analytic functions, time buckets, gap fitting and continuous aggregates. In the case of the last of these, this has recently (version 1.4) been extended to support multiple continuous aggregates against each hypertable where previously only one was supported. Also noteworthy is support for ordered appends, which optimise a variety of queries but especially those ordered by time.

Fig 02 Comparing ingestion rates with PostgreSQL

Why you should care rather depends where you are coming from. If you are an existing PostgreSQL user who wants improved ingestion and query performance for time-based analytics, then TimescaleDB represents an obvious starting point and Figure 2 (supplied by Timescale) represents a good reason why you might add TimescaleDB to your existing environment. A similar argument would apply if you are a relational database user in general and want to explore time-series with lower latency and better performance.

More generally, there is the case where you want to be able to exploit time-series data but don’t have any existing database that you want to replace or extend. In this event TimescaleDB has a number of differentiators and advantages, though which of these will be relevant will be dependent on the potential competition. First off, while Timescale focuses on analytics it is a transactional database, and many IoT use cases involve both operational and analytic capabilities. Secondly, not only does TimescaleDB use SQL, it is a relational database and it will often be the case that you want to combine relational and time-series data. Thirdly, the company can offer geo-spatial capabilities, through PostGIS, that are sadly lacking in some competitive offerings. And finally, TimescaleDB has a relatively small footprint – you can implement it on a Raspberry Pi – so it can be implemented in suitable edge devices.

All of that said, even though TimescaleDB is a relatively new offering, it builds on PostgreSQL and therefore inherits the reliability and stability from its decades of existence. The question is whether this is a preferable approach compared to a purpose-built time-series database. The imminent release of a distributed version of TimescaleDB, along with improved native compression, suggests that the company is determined to prove that this should not be an issue.

The Bottom Line

Timescale has established itself as a major player in the time-series market, despite its relative youth. This is primarily because of its relational heritage but, whatever the reason, it is certainly a major contender within this marketplace.
